Royall Pressurized 6100 Indoor Wood/Coal Boiler – 90,000 btu
(100,000 btu based on wood calculations of a Manual J Rating)
Our smallest residential indoor wood/coal boiler puts out an amazing 90,000 btu with a small footprint. The perfect residential boiler for smaller homes under 1,800 sq feet in area. The Royall boiler series provides, even, whole house comfort and the technology to keep you comfortable no matter what mother nature throws at you.
Boiler Specifications:
• 51″ x 26″ x 28″ (HxWxD)
• 41.25″ Flue Center To Ground
• 1/4″ and 5/16″ Steel Construction
• Quality Powder Coated Finish
• (2) Cast Iron Stationary Grates
• 50 cfm Forced Draft Fan
• Auto Damper Shutoff
• 4.75 Cu ft Firebox Capacity
• 28 Gallon Water Capacity
• 10″ x 14″ Fuel Door
• 5″ x 7″ Ash Removal Door
• 20″ Log Length
• (8) 9″x4.5″x1.25″ Firebricks
• 6″ Flue
• 1-1/4″ FNPT Connections
• 530 lbs (approximate)
• Rated for UL391
